2009 Edition Part 2 Figure 2B-20. Roundabout Signs and Plaques

Full-size image of Figure 2B-20

Figure 2B-20. Roundabout Signs and Plaques

This figure shows four roundabout signs and plaques.

R16-4 is shown as a horizontal rectangular white sign with two right-pointing black chevrons.

R16-4a is shown as a horizontal rectangular white sign with three right-pointing black chevrons.

R16-4b is shown as a horizontal rectangular white sign with four right-pointing black chevrons.

R16-5P is shown as a square white sign with a black border and legend with three left-pointing semicircular arrows one behind the other arranged in a circle.
