2009 Edition Part 2 Figure 2B-24. Parking and Standing Signs and Plaques (R7 Series) (Sheet 1 of 2)

Full-size image of Figure 2B-24, Sheet 1

Figure 2B-24. Parking and Standing Signs and Plaques (R7Series) (Sheet 1 of 2)

This figure shows 25 parking and standing signs and plaques on two sheets.

Sheet 1 shows 19 signs.

R7-1 is shown as a vertical rectangular white sign with a red border and the words "NO PARKING" in large red letters on the top two lines and the words "ANY TIME" in red on the next two lines. A left-pointing horizontal red arrow is shown on the fifth line.

R7-2 is shown as a vertical rectangular white sign with a red border and a black letter "P" inside a red circle with a diagonal red slash across it. The words "8:30 AM to 5:30 PM" are shown in red on two lines under this symbol.

R7-2a is shown as a vertical rectangular white sign with a red border and the words "NO PARKING" in large red letters on the top two lines and the words "8:30 AM to 5:30 PM" in red on the next two lines. A right-pointing horizontal red arrow is shown on the fifth line.

R7-3 is shown as a vertical rectangular white sign with a red border and the words "NO PARKING" in large red letters on the top two lines above the words "EXCEPT SUNDAYS AND HOLIDAYS" in red on the next three lines. A two-direction horizontal red arrow is shown on the sixth line.

R7-4 is shown as a vertical rectangular white sign with a red border and the word "NO" in large red letters on the top line above the words "STANDING ANY TIME" in red on the next three lines. A two-direction horizontal red arrow is shown on the fifth line.

R7-5 is shown as a vertical rectangular white sign with a green border and the words "ONE HOUR PARKING 9 AM-7 PM" in green on four lines. A two-direction horizontal green arrow is shown on the fifth line.

R7-6 is shown as a vertical rectangular white sign with a red border and the words "NO PARKING" in large red letters on the top two lines above the words "LOADING ZONE" in red on the next two lines. A two-direction horizontal red arrow is shown on the fifth line.

R7-7 is shown as a vertical rectangular white sign with a red border and the words "NO PARKING" in large red letters on the top two lines and the words "BUS STOP" in red on the next two lines. Aright-pointing horizontal red arrow is shown on the fifth line.

R7-8 is shown as a vertical rectangular white sign with a green border and the words "RESERVED PARKING" in green on two lines above a blue handicapped symbol. A two-direction horizontal green arrow is shown below the symbol.

R7-8P is shown as a horizontal rectangular white supplemental plaque with a green border and the words "VANACCESSIBLE" in green on two lines.

R7-20 is shown as a horizontal rectangular white sign with a green border and legend. It shows a large stylized symbol of a hand holding a coin to the left of the words "1 HOUR" on two lines above a vertical arrow pointing down.

R7-21 is shown as a vertical rectangular white sign with a green border and a black letter "P" inside a green circle. The words"1 HOUR PAY PARKING" are shown in green on three lines under this symbol. A right-pointing horizontal green arrow is shown on the fifth line.

R7-21a is shown as a vertical rectangular white sign with a green border and a black letter "P" inside a green circle. The words"PAY PARKING 15 MINUTE LIMIT" are shown in green on four lines under this symbol. A right-pointing horizontal green arrow is shown on the fifth line.

R7-22 is shown as a vertical rectangular white sign with a green border and a black letter "P" inside a green circle. The words"PAY PARKING" are shown in green on two lines under this symbol. A right-pointing horizontal green arrow is shown on the fourth line.

R7-23 is shown as a vertical rectangular white sign with a green border and a black letter "P" inside a green circle. The words "8:30 AM to 5:30 PM" in green are shown on the next two lines. A two-direction horizontal green arrow is shown on the fourth line.

R7-23a is shown as a vertical rectangular white sign with a green border and a black letter "P" inside a green circle. The words "1 HOUR 7 AM - 6 PM" in green are shown on the next two lines. A two-direction horizontal green arrow is shown on the fourth line.

R7-107 is shown as a vertical rectangular white sign with a red border and the words "NO PARKING" in a panel in the top fourth of the sign. The word "NO" is shown in large white letters on a red panel in the upper left quadrant of the sign to the left of the word "PARKING" in red. Below this panel, the words "BUS STOP" in red are shown on two lines above a right-pointing horizontal red arrow.

R7-107a is shown as a vertical rectangular white sign with a red border. In the top third of the sign, a panel is shown with the words "THIS AREA MAY BE USED FOR A TRANSIT LOGO. (IF NOT USED DECREASE SIGNHEIGHT BY 6 INCHES)" in black. Below this panel, a black head-on bus symbol is shown above a black letter "P" inside a red circle with a diagonal red slash across it. A right-pointing horizontal red arrow is shown at the bottom of the sign.

R7-108 is shown as a vertical rectangular white sign with a green border and the words "2 HR PARKING" in a panel in the top third of the sign. The numeral "2" in white is shown on a green panel in the upper left of the sign to the left of the words "HR PARKING" in green on two lines. Below this panel, the words "8:30 AM to 5:30 PM" in green are shown on two lines above a two-direction horizontal green arrow.
